Introduction:Custom Commutator VDT60-2K
| Series | Single-stage | |||
| Ratio *1 | Recommended | 2 | 3 | 5 |
| Nominal torpue TN | Nm | 25 | 23 | 15 |
*1、Ratio i=Nin/Nout (Input speed/output speed)
"2、High/low temperature grease can be customized according to the use environment.
| Content | Unit | Single-stage | ||
| Max. acceleratiom torque | Nm | 1.6times rated torpue | ||
| Max. output torque | Nm | 2.0times rated torpue | ||
| Backlash | P2 arcmin | ≤8 | ||
| Rated input speed | rpm | 3000 | ||
| Max. input speed | rpm | 4500 | ||
| Maximum efficiency | % | 96% | ||
| Use of temperature | ℃ | -15°~+40° | ||
| Working temperature | ℃ | -25°~ +90° | ||
| Lifetime | h | 20000 | ||
| Lubrication *4 | Life lubrication | |||
| Degree of protection | IP | IP65 | ||
| Noise | dB | ≤70 | ||
| Weight | kg | ≈1.4 | ||
